November 7, 2023, 3:40 pm | Read time: 5 minutes
Anyone dealing with graphics cards or computer monitors inevitably encounters a lot of technical jargon. An important term here is V-Sync, as well as FreeSync and G-Sync. But what exactly are these, and do they refer to the same thing?
In gaming, the image can sometimes appear torn and show stripes. This not only looks unattractive but can also significantly disrupt the gaming experience in the worst case. This effect is called “screen tearing”–a rather descriptive term. V-Sync, along with FreeSync and G-Sync, is a technology that can prevent this effect. But how does it work exactly? TECHBOOK explains the terms and the technology behind them.
Overview
Screen Tearing Effect Explained
The GPU (Graphics Processing Unit) indicates the refresh rate in FPS, frames per second. If this value is, for example, 60, it means that 60 frames can be calculated per second. The higher the FPS value, the smoother the image. A monitor, on the other hand, indicates its refresh rate in hertz.
However, if the GPU sends, for example, 90 frames per second, of which the monitor can only display 60, some of the sent frames may not build up correctly. While the monitor is still busy uploading the image correctly, the GPU is already sending the next set.
This leads to the so-called screen tearing. The resulting stripe effect can be visible both horizontally and vertically. However, the horizontal variant is more common. Generally, the GPU has a higher FPS rate than the monitor’s hertz. The reverse is much rarer and does not lead to such significant problems. Only if the FPS rate is significantly lower than the monitor’s hertz can the image appear a bit choppy.
Don’t want to miss any important news or guides on the topic? Then subscribe to us on WhatsApp!
What Is the Difference Between FPS and Hz in Monitors?
What Equipment Do I Need for PC Gaming?
How V-Sync and Co. Can Help with Screen Tearing
But what to do if unsightly stripes constantly appear on the screen while watching videos or gaming? You could simply buy a new monitor with a refresh rate that matches the GPU. Or you could look for hardware that features the so-called V-Sync technology.
How V-Sync Works and What Are the Pros and Cons?
V-Sync stands for “vertical synchronization” and refers to a graphics technology used in gaming to prevent the aforementioned phenomenon of “screen tearing.” V-Sync, or vertical synchronization, aims to align the GPU’s image output with the monitor’s refresh rate. AMD’s FreeSync and Nvidia’s G-Sync are two different implementations of this technology.
To do this, V-Sync limits the GPU’s frame rate to match the monitor’s refresh rate, adjusting it downward. So-called adaptive V-Sync can also prevent the reverse effect. If the FPS rate falls below the monitor’s refresh rate due to V-Sync, the calculation adjusts accordingly.
To compensate for the screen tearing effect, V-Sync technology uses a so-called frame buffer. This means that the images the monitor is supposed to display are essentially pre-produced. This is not a problem for single-player games. However, if you want to play multiplayer titles, you may have to deal with slight delays in image playback with V-Sync enabled.
Also interesting: The best gaming monitors–and what gamers need to consider when buying
FreeSync by AMD
The major graphics card manufacturers AMD and Nvidia each rely on V-Sync technology, but in individual forms. AMD FreeSync uses the Adaptive-Sync standard and creates dynamic communication between your GPU and a FreeSync-capable monitor.
When the GPU’s frame rate fluctuates, FreeSync dynamically adjusts the monitor’s refresh rate to prevent screen tearing. FreeSync is cost-effective because it does not require specialized hardware modules in monitors, making it accessible to a broader range of users.
G-Sync by Nvidia
G-Sync is Nvidia’s proprietary technology and requires specialized hardware in both the monitor and the GPU. Similar to FreeSync, G-Sync dynamically synchronizes the GPU’s frame rate and the monitor’s refresh rate. Unlike AMD’s technology, G-Sync is more finely tuned, completely eliminating screen tearing and stuttering.
Both AMD FreeSync and Nvidia G-Sync enhance the gaming experience by preventing screen tearing through adaptive synchronization. FreeSync is an open standard and found in many modern monitors and TVs. Unlike the proprietary G-Sync technology, FreeSync only reduces screen tearing–and does not completely prevent it.
When Hardware with V-Sync Is Worth It
Whether to invest in devices with the corresponding technology depends heavily on individual needs. In the video sector, reasonably modern monitors should handle most content. The bigger issue lies in gaming. New games also require increasingly higher performance from the graphics card, which usually involves a steady increase in the necessary FPS rate.
So if you want the most unrestricted gaming experience with smooth, stripe-free images, you’ll eventually need to upgrade your hardware. A V-Sync-capable device can be cheaper than a monitor with a high hertz rate. However, if you play many online games, you should consider the minimal time delay that can occur and possibly opt for a monitor with the appropriate hertz values.
